Brass Angle weight Chart

Quick answer: Brass equal angle weight (kg/m) = t × (2a − t) × 0.0085, where a is the leg and t the thickness in mm. Example: a 20 × 20 × 2 mm brass angle weighs about 0.65 kg/m, or 3.9 kg for a 6 m length.

Brass Angle size and weight chart

SL	Description	Size	Thickness	Length (m)	Weight Kg/m	6 Meter Weight
1	Brass Angle	8×8 mm	1	6	0.128	0.768
2	Brass Angle	10×10 mm	1	6	0.163	0.978
3	Brass Angle	12×12 mm	1	6	0.197	1.182
4	Brass Angle	15×15 mm	1	6	0.248	1.488
5	Brass Angle	15×15 mm	1.5	6	0.366	2.196
6	Brass Angle	15×15 mm	2	6	0.479	2.874
7	Brass Angle	15×15 mm	3	6	0.693	4.158
8	Brass Angle	20×20 mm	1	6	0.334	2.004
9	Brass Angle	20×20 mm	1.5	6	0.494	2.964
10	Brass Angle	20×20 mm	2	6	0.651	3.906
11	Brass Angle	20×20 mm	3	6	0.95	5.7
12	Brass Angle	25×25 mm	1.5	6	0.623	3.738
13	Brass Angle	25×25 mm	2	6	0.822	4.932
14	Brass Angle	25×25 mm	3	6	1,207	7242
15	Brass Angle	30×30 mm	2	6	0.993	5.958
16	Brass Angle	30×30 mm	3	6	1,464	8784
17	Brass Angle	40×40 mm	3	6	1,977	11862
18	Brass Angle	50×50 mm	3	6	2	14.946

Brass Square Tube Weight Chart

Download PDF:Download Brass Angle Weight Chart (PDF)

How to calculate brass angle weight

Cross-section area (mm²) = t × (2a − t). Multiply by 0.0085 for kg/m (brass density 8,500 kg/m³).

15 × 15 × 1.5 mm: 0.36 kg/m
25 × 25 × 3 mm: 1.20 kg/m
40 × 40 × 3 mm: 1.96 kg/m

Brass angles are used for stair nosing, tile trims, edge protection and decorative frames.

Buying brass or other metals in the UAE? WhatsApp 058 566 7721 for stock and price, or build your list in the metal weight and cost estimator.

Frequently asked questions

What is brass angle used for?

Stair nosing, tile and floor trims, edge guards, frames and architectural details.

How heavy is brass compared with steel?

Brass is about 8% heavier than steel for the same size (8,500 vs 7,850 kg/m³).

What length is brass angle?

Typically 3 m or 6 m lengths.
