BRC Mesh weight chart

Quick answer: BRC mesh is welded steel reinforcement mesh sold in 2.4 × 4.8 m sheets (11.52 m²). Common square meshes weigh about A142 = 2.22 kg/m², A193 = 3.02 kg/m², A252 = 3.95 kg/m² and A393 = 6.16 kg/m², so an A193 sheet weighs about 34.8 kg.

Buying BRC mesh in Dubai or the UAE?
We supply BRC mesh from stock in Dubai Industrial City. See sizes and weight charts for BRC mesh or get a quote on WhatsApp (058 566 7721).

Updated November 2026. BRC (welded wire) mesh is sold in standard 2.4 × 4.8 m sheets (11.52 m²). The quick weights below are the most asked for; the full BS 4483 table follows.

  • A393 (10 mm wire, 200 × 200): 6.16 kg/m², about 71.0 kg per sheet
  • A252 (8 mm wire, 200 × 200): 3.95 kg/m², about 45.5 kg per sheet
  • A193 (7 mm wire, 200 × 200): 3.02 kg/m², about 34.8 kg per sheet
  • A142 (6 mm wire, 200 × 200): 2.22 kg/m², about 25.6 kg per sheet
BRC Mesh weight chart
SL BRC Mesh BS4483 Fabric Mesh Size Normal Diameter of Wire Cross Section Area Normal Mass No of Sheets Full Sheet
Size (M) BRC wire mesh standard size weight chat Pitch of Wires Per Metre Width Per m2 Per Ton
Main Cross Main Cross Main Cross
mm mm mm mm mm2 mm2 kg
No Type A mesh Square Mesh  weight in KG
1 2.4×4.8 A98 200 200 5 5 98 98 1.54 57 17.74
2 2.4×4.8 A142 200 200 6 6 142 142 2.22 40 25.57
3 2.4×4.8 A193 200 200 7 7 193 193 3.02 29 34.79
4 2.4×4.8 A252 200 200 8 8 252 252 3.95 22 45.50
5 2.4×4.8 A393 200 200 10 10 393 393 6.16 15 70.96
Type B Mesh Rectangular Mesh/ Structural Mesh  weight in KG
1 2.4×4.8 B1131 100 200 12 8 1131 252 10.9 8 125.57
2 2.4×4.8 B785 100 200 10 8 785 252 8.14 11 93.77
3 2.4×4.8 B503 100 200 8 8 503 252 5.93 15 68.31
4 2.4×4.8 B385 100 200 7 7 385 193 4.53 20 52.19
5 2.4×4.8 B283 100 200 6 7 283 193 3.73 24 42.97
6 2.4×4.9 B196 100 200 5 7 196 193 3.05 29 35.14
 Type C Mesh Rectangular  /Long Mesh  weight in KG
1 2.4×4.8 C785 100 400 10 6 785 70.8 6.72 13 77.41
2 2.4×4.8 C636 100 400 9 6 636 70.8 5.55 16 63.94
3 2.4×4.8 C503 100 400 8 5 503 49 4.34 21 50.00
4 2.4×4.8 C385 100 400 7 5 385 49 3.41 26 39.28
5 2.4×4.8 C283 100 400 6 5 283 49 2.61 34 30.07
Type W Mesh Wrapping Mesh  weight in KG
1 2.4×4.8 D49 100 100 2.5 2.5 49 49 0.77 113 8.8704
Weight in KG
1 2.4×4.8 SQ196 100 100 5 5 196 196 3.07 28 35.37
2 2.4×4.8 SQ282 100 100 6 6 282 282 4.44 20 51.15
3 2.4×4.8 SQ385 100 100 7 7 385 385 6.04 14 69.58
4 2.4×4.8 SQ503 100 100 8 8 503 5.3 7.9 11 91.01
5 2.4×4.8 SQ785 100 100 10 10 785 785 12.33 7 142.04
6 2.4×4.8 SQ1131 100 100 12 12 1131 1131 17.76 5 204.60
Type Q /S  weight in KG
1 2.4×4.8 Q131-SPL 150 150 5 5 131 131 2.05 43 23.62
2 2.4×4.8 Q188-SPL 150 150 6 6 188 188 2.96 30 34.10
3 2.4×4.8 S257 150 150 7 7 257 257 4.03 22 46.43
4 2.4×4.8 S335 150 150 8 8 335 335 5.27 17 60.71
5 2.4×4.8 S524 150 150 10 10 524 524 8.22 11 94.69
6 2.4×4.8 S754 150 150 12 12 754 754 11.84 8 136.40
MS Grating Weight Chart BRC welded reinforcement mesh panels

How BRC mesh weight is calculated

The number in the mesh name is the steel area in mm² per metre width. For square A-type mesh the same area runs in both directions, so:

Weight per m² = (main area + cross area) × 0.00785. For A393: (393 + 393) × 0.00785 = 6.17 kg/m². Sheet weight = kg/m² × 11.52, so an A393 sheet is about 71 kg.

Which mesh to use

  • A142 and A193: ground slabs, footpaths, light floors and screeds
  • A252: general slabs, driveways and car parks
  • A393: heavier slabs, retaining walls and industrial floors
  • B-type (rectangular) mesh: structural slabs where more steel is needed in one direction

Always follow the mesh type shown on the structural drawings.

Frequently asked questions

What is the weight of an A393 BRC mesh sheet?

About 71 kg for a standard 2.4 × 4.8 m sheet (6.16 kg/m² × 11.52 m²).

How many A252 sheets are in one ton?

About 22 sheets of 2.4 × 4.8 m.

What is the size of a standard BRC mesh sheet?

2.4 m × 4.8 m, which is 11.52 m². Other sizes can be made to order.
