Aluminum alloy chart
Normal Aluminum alloy chart
| SL | Aluminum Alloy | Aluminum Density in kg/m³ |
| 1 | Aluminum (average) | 2700 |
| 2 | Melted aluminum | 2600 |
| 3 | Aluminum 1050 | 2710 |
| 4 | Aluminum 1100 | 2720 |
| 5 | Aluminum 3103 | 3730 |
| 6 | Aluminum 5005 | 2700 |
| 7 | Aluminum 5083 | 2650 |
| 8 | Aluminum 5215 | 2690 |
| 9 | Aluminum 5454 | 2690 |
| 10 | Aluminum 5754 | 2660 |
| 11 | Aluminum 6005 | 2700 |
| 12 | Aluminum 6063 | 2700 |
| 13 | Aluminum 6082 | 2700 |
| 14 | Aluminum 7075 | 2800 |
Typical end uses Aluminum alloy chart
| SL | Alloy | Typical end uses | Density (kg/cm3) |
| 1 | 2024 | High strength aerospace | 0.00278 |
| 2 | 3003 | Formed heat exchangers | 0.00273 |
| 3 | 5083 | Marine use | 0.00266 |
| 4 | 6060 | General commercial use | 0.0027 |
| 5 | 6061 | High/medium strength commercial use | 0.0027 |
| 6 | 6063 | General commercial use | 0.0027 |
| 7 | 6063A | Consistent forming | 0.0027 |
| 8 | 6082 | High strength commercial use | 0.0027 |
| 9 | 6463 | High polish level commercial use | 0.00269 |
| 10 | 7075 | Highly stressed structural parts | 0.00281 |
Basic formula
Aluminum extrusion basic formula for weight per meter is: Cross sectional area (mm2) x Density (kg/cm3) = Theoretical weight per meter (kg/m)
Download PDF: Aluminum-Alloy-Conversion-Chart
